| SDX-90.2 FULL RANGE DIGITAL FEATURES |
| • High Efficiency Digital Multi-Channel Design |
| • 12 dB/Octave – Variable High Pass Filter |
| • 12 dB/Octave – Variable Low Pass Filter |
| • DC Auto sense feature |
| • 4 Way Protection Ciruit (Thermal, Voltage, Speaker Short, DC Offset) |
| • Optional Wired Remote Control |
| SPECIFICATIONS (Tested @ 14.4v) | |
| 4 ohm Bridged RMS | 240W |
| 2 ohm Mono RMS | 120W x 2 |
| 4 ohm Mono RMS | 90W x 2 |
| Recommended Fuse Rating | 25A |
| Low Pass Filter (Variable) | 30Hz-500Hz |
| High Pass Filter (Variable) | 15Hz-500Hz |
| Input Sensitivity (+/- 5%) | 6v Max |
| S/N Ratio | 78dB |
| Working Voltage | 11.5v-15.0v |
| Dimensions | 4.125″ x 5.825″ x 2.125″ |
